Description： 1.We adopt the internationally advanced DSP control technology,arrange high-speed cutting control software,own the buffer function in high-speed movement and uses USB interface to transmit data, can greatly impove working efficience. 2.Compared with domestic guide, this model used the imported AMT line which work as twice than others. 3.It uses professional BS step motor and driver system. 4.Mirror and lens are made of imported fibrous material, which can endure high temperature.



Applicable Industries： cloth, embroider, fabric toy, furniture, reticule, glove, bag, leather engravinglcutting. model advertising, decoration, electric product, rubber, acrylic product, middle density board etc nonmetal sheet precision cutting.

Applicable Materials： wood, paper, leather, cloth, organic glass, resin, acrylic, wollens, plastic, rubber, ceramic tile, crystal, bowlder, bamboo.

Parameters of Products ： TYPE BS－1290 BS－1290B BS－1290II
Engraving area 900×1200mm
Engraving speed 0-64000mm/min(stepless speed regulating)
Laser power 80W
Resolution ratio 0.025mm
Minimum shaping character Chinese Character2mm letter1mm
Resetting positioning accuracy ±0.01mm
Power supply AC200V±10%,50HZ
Gross power <1250W
Operating temperature 0℃-45℃
Operating humidity 5%-95%(free of condensed water)
Graphic format supported BMP、GIF、JPEG、PCX、TGA、TIFF、PLT、CDR、DWG、DXF
Net weight 250KG
Dimension 1800×1400×1100mm
Options Cooling box   honeycomb board
